HARDWARECONFIGURATION硬件配置参数:
Image Pickup Device 图像传感器 | SONY ICX282AQ CCD （彩色） |
Scan Mode 扫描模式 | Interlaced 隔行扫描 |
Max. Resolution Zui高分辨率 | 2560 x 1920 (Approx. 4900,000 Pixels) |
Sensor Size (Diagonal) 传感器尺寸 | 2/3“ (Diagonal 11mm) |
Pixel Size 像元尺寸 | 3.4µm x 3.4µm |
Imaging Area 传感器有效影像区域 | 9.74mm(H) x 7.96mm(V) |
G Sensitivity 灵敏度 | 260mV with 1/30s Accumulation |
Dynamic Range 动态范围 | 70dB |
A/D Converter 模数转换 | 12-bit Parallel, 8-bit R.G.B to PC |
SN Ratio 信噪比 | 62dB |
Spectral Range 光谱响应 | 380-650nm (with IR-filter) |
Video Format & Frame Rate 视频模式 | 4fps @2560 x 1920, 9fps @1280 x 960 (Multiple Speed Level) |
Binning 像素叠加 | 1 x 1, 2 x 2 |
Exposure 曝光能力 | 0.203ms~104.899ms, ROI Auto & Manual |
White balance 白平衡 | One Push ROI White Balance/ Manual Temp-Tint Adjustment |
Color Rendering Technique 色彩渲染技术 | Ultra FineTM Color Engine |
Peak Quantum Efficiency 峰值量子效率 | 35% |
Readout Noise 读出噪音 | N/A |
Extinction Ratio 消光比 | N/A |
Smear | N/A |
Capture/Control API 软件接口 | DirectShow , Twain |
Recording System 记录模式 | Still Picture and Movie |
Cooling System* 制冷系统 | Nature, Optional: PELTIER (Semiconductor Cooling Module) |
OPERATINGENVIRONMENT操作及存储环境要求:
Operating Temperature 工作温度 | -10℃~ 50℃ |
Storage Temperature 储存温度 | -20℃~ 60℃ |
Operating Humidity 工作湿度 | 30~80%RH |
Storage Humidity 储存湿度 | 10~60%RH |
Power Supply 供电 | DC 5V over PC USB port |
SOFTWAREENVIRONMENT软件运行环境要求:
Operating System 操作系统 | Microsoft® Windows® XP / Vista / 7 (32 & 64 bit) |
PC Requirements 电脑配置 | CPU: Equal to Intel Core2 2.8GHz or higher |
Memory:2GB or more | |
Display:17" or larger | |
CD-ROM |
